Grid Rig 400
434 kWh mobile energy storage & charging station
Grid Rig 400 is a high-capacity mobile energy storage system built for heavy-duty charging and industrial power supply. With 434kWh of onboard storage and up to 180kW DC fast charging, it supports larger vehicles, extended runtime and multi-shift operations. Designed for rugged field conditions, Grid Rig 400 integrates CCS fast charging and liquid-cooled thermal management to maintain performance in extreme environments. It is well suited to mining sites, industrial parks and remote infrastructure where reliable, scalable power is critical.
90kW
Shared max output
CCS2
Dual Guns
Mine Spec
Optional upgrade
200-1000 Vdc
Charging output voltage range
Size
2750 x 1750 x 1700 mm
4,200 kg
Battery size
434kWh
180kW
Max Output
Technical Specifications
Battery Size
434kWh
Max Output
180kW
Specifications
Model ID
GR 400
Battery pack capacity
434kWh
Battery pack voltage
672V
Total max output
180kW
Shared max output
90kW
Charging equipment
CCS2
Charging
Dual Guns
Charging output voltage range
200-1000 Vdc
Communication protocol
OCPP1.6J
DC energy replenishment
250A (CCS Charging dock optional)
Current output
100kW Indust. sockets (380~480V 125A x 1, 63A x 2)
Mine Spec
Yes, optional upgrade
AC replenishment method
125A / 63A (Industrial socket)
Operating temperature range
-10 — 60°C
Ingress protection ratings
Overall machine IP54 / energy storage IP67
Battery life cycle
> 5000 Cycles (90% DOD, 80% EOL)
Thermal management
Liquid cooling
Device Interface
10-Inch touchscreen (HMI)
Housing construction
Sheet metal
Size (L x W x H)
2750 x 1750 x 1700 mm
Weight
4,200 kg
Applications & use cases
Ports & Wharves
Electrify maritime port infrastructure with port electrification solutions. Reduce emissions and environmental impact and create a sustainable grid.
Off-grid Hybrid Systems
Explore reliable off-grid power solutions with battery power and solar systems. Specializing in off-grid solar systems and grid-tie setups.
Excavator & Equipment Suppliers
Support electric equipment sales with mobile charging solutions. Help customers overcome charging barriers with packages for excavators and machinery.
Airports Terminal Services
Airside EV charging for airport ground service vehicles. Mobile charging for electric vehicles at terminals, airside car parks, and airside operations
Mining & Construction
Discover tailored EV charging solutions for mining & construction. Power your electric vehicles with robust infrastructure in rugged environments..
Mine spec
Mine site & Industrial Specification
Every Grid Rig model can be upgraded to meet demanding mining and industrial site requirements. Designed for harsh Australian environments, our Mine & Industrial Specification package adds enhanced durability, weather protection and site safety features to ensure reliable operation wherever the job takes you.
Corrugated Side Panels
Strengthened corrugated panels improve structural rigidity while allowing quick access for servicing.
2mm Heavy-Gauge Steel
Upgraded 2mm sheet steel provides greater durability and impact resistance.
Mine Site Reflective Strips
High-visibility reflective markings improve safety and help prevent accidental collisions.
Reinforced Lift Points
Heavy-duty lifting points are designed for repeated transport and crane handling.
Protected Charging Cradle
A sealed charging cradle helps shield the connector from dust, water spray and harsh site conditions.
Available across the entire Grid Rig range, our Mine & Industrial Specification package can be tailored to suit your site requirements and compliance standards.
Mine spec available
Megawatt Charging for Industrial Operations
Built around next-generation Megawatt Charging System (MCS) technology, the GR 300MCS is designed to support the rapid electrification of heavy industry. With up to 1.5MW of charging power, it can significantly reduce charging times for large electric assets such as mining equipment, haul trucks, construction machinery, port vehicles and heavy transport fleets.
THE TECH
Smart Technology
Smart Control for Liquid Cooling and Heating
Intelligent cooling and heating system is designed to maintain optimal operating temperatures for the entire system, ensuring stability and efficiency in any environment. When the ambient temperature reaches a pre-set threshold, the system automatically activates either cooling or heating mode.
This intelligent temperature regulation ensures that the system remains within a normal operating temperature range, enhancing reliability and longevity. Whether in extreme cold or heat, the system provides a robust solution for maintaining peak performance.
Fire safety
Battery Compartment Protection
Advanced fire safety measures are in place to effectively mitigate potential fire risks in the battery compartment.
Electrical Compartment Fire Safety
Advanced fire safety measures are in place to effectively mitigate potential fire risks in the battery compartment.
Flame Retardant Insulation
Flame retardant insulation on the metal top acts as an additional heat and fire barrier, improving overall safety.
Firefighting System
A built-in firefighting system automatically activates during a fire, minimising damage and ensuring safety.
