Grid Rig 2M
2 MWh industrial energy storage & charging station
Grid Rig 2M is a large-scale mobile energy storage and charging system engineered for industrial-level power demand. With up to 2MWh of battery capacity and support for six simultaneous 200kW DC charging outputs, it delivers high-volume energy for large fleets, heavy machinery and critical infrastructure. Built to operate in extreme conditions, Grid Rig 2M offers adaptable voltage ranges, advanced communication protocols and extensive industrial power outputs. It provides a robust off-grid alternative for mining operations, large logistics facilities and temporary or remote power deployments where uptime and capacity are non-negotiable.
200~1000 VDC
Charging output voltage range
200KW
Dual gun output
Size
6058 x 2438 x 2591mm
25,000 kg
Battery size
2MWh
1MW
Max Output
Technical Specifications
Battery Size
2MWh
Max Output
1MW
Specifications
Model ID
GR 2M
Battery pack capacity
2MWh
Battery pack voltage
AVR 500~1500Vdc
Charging cables
200KW x 6 (6 guns) (CCS1/CCS2 plug optional)
Max charging output (single)
1MW
Max charging output (multi)
200KW
Charging guns (up to)
Six
Charging output voltage range
200~1000 VDC
Communication protocol
OCPP1.6J, Modbus-TCP/IEC61850/104
DC energy replenishment
200A CCS2
Current output
500kW (380V industrial (400A x 1) (200A x 1) (125A x 1)
AC replenishment method
500kW (Industrial Socket)
Operating temperature range
-40 - 60°C
Ingress protection ratings
Overall machine IP54 / energy storage IP67
Battery life cycle
>5000 cycles (90% DOD, 80% EOL)
Thermal management
Liquid cooling
Device Interface
10-Inch touchscreen (HMI & EMS)
Housing construction
Sheet metal
Size (L x W x H)
6058 x 2438 x 2591mm
Weight
25,000 kg
BMS scheme
Active balancing + three-level architecture
Maximum Power Point Tracking
500KW is optional, PV/DC300~1000V
Fire protection management
Gas, smoke, temperature detection
Insulation resistance
>10MΩ
Elevation resistance
≤2000m
Allowable relative humidity
0~95RH (No cold dew)
Communication interfaces
Ethernet/RS485/CAN
Corrosion protection level
C4 (C5 optional)
Applications & use cases
Airports Terminal Services
Mobile EV charging for airport ground support equipment. Charge baggage tugs, cargo loaders, and terminal vehicles with deployable solutions.
Off-grid Hybrid Systems
Mobile battery energy storage for off-grid and hybrid power systems. Integrate solar, reduce diesel dependency. 100kWh to 2MWh capacity.
Plant Hire & Heavy Machinery
Mobile energy storage and EV charging for plant hire and heavy machinery operating across multiple sites.
Ports & Wharves
Mobile charging solutions for port electrification. Charge terminal tractors, straddle carriers, and container handling equipment.
Mining & Construction
Deploy mobile battery-powered EV charging across remote mining and construction sites. 100-420kWh capacity, AS3000 compliant.
THE TECH
Smart Technology
Smart Control for Liquid Cooling and Heating
Intelligent cooling and heating system is designed to maintain optimal operating temperatures for the entire system, ensuring stability and efficiency in any environment. When the ambient temperature reaches a pre-set threshold, the system automatically activates either cooling or heating mode.
This intelligent temperature regulation ensures that the system remains within a normal operating temperature range, enhancing reliability and longevity. Whether in extreme cold or heat, the system provides a robust solution for maintaining peak performance.
Fire safety
Battery Compartment Protection
Advanced fire safety measures are in place to effectively mitigate potential fire risks in the battery compartment.
Electrical Compartment Fire Safety
Advanced fire safety measures are in place to effectively mitigate potential fire risks in the battery compartment.
Flame Retardant Insulation
Flame retardant insulation on the metal top acts as an additional heat and fire barrier, improving overall safety.
Firefighting System
A built-in firefighting system automatically activates during a fire, minimising damage and ensuring safety.
